CNC-grinding machine with three or four axes and vertical grinding spindle for surface grinding of knives, scissors, hand tools and related parts
• 30% less required space in comparison to the horizontal arrangement of the grinding spindle
• Good stability thanks to a solid welded construction of the machine housing
• Prevention of vibrations during processing due to a machine housing filled up with mineral cast
• User-friendly, Windows-based controls with interfaces for robotics, PLC, measuring technology and other applications
• "Esprit" CAM interfaces
• Wear-free main axis drive with linear motor, achieving rapid traverse speeds of 240'/min
• Precision, backlash-free positioning, using direct measuring system
• Compact, precision gearbox with high rigidity to control rake angle
• As a single or a double machine available due to two separate machine housings
