New generation of operator panels for high-end CNC applications

Chicago – The Sinumerik blackline panels OP 015 black and OP 019 black are a new generation of operator panels for the Sinumerik 840D sl CNC system and offer new options for machine operation. The inductive sensor technology enables rapid interaction with the user interface even when the operator is wearing gloves. Similarly, it prevents incorrect entries such as those caused by the heel of the operator‘s hand.



The 19" display of the OP 019 black can show all the entries made in widescreen format at a glance. The OP 015 black also features an alphanumerical keypad on the right that can be operated via touch control. This feature means that the 15" display is not restricted by the superimposed keypad during data entry, which ensures clear and efficient operation. Both blackline panels also have an integrated glass panel on the front side and are designed with IP65 (OP 019 black) and IP66 (OP 015 black) degrees of protection. They are resistant to liquids and dust and can be operated under harsh industrial conditions. An integrated key lock helps safeguard against operating errors. The operator panel can provide a basic machine display, with three or four channels showing up to 13 axes.



The blackline panels also feature durable LED background lighting, providing 40% energy-savings compared to conventional neon lamps.



In combination with the Sinumerik 840D sl control, for use on high-end milling, turning, grinding, and laser-cutting machine tools, the blackline panels can be used as an operating and programming station for aerospace composite machining, power generation, and medical part manufacturing, in addition to tool- and mold-making, rotary indexing machines, and in shopfloor manufacturing.



Source: Siemens Industry Inc.
