Lévis, Québec, Canada – Creaform, known for its portable 3D measurement solutions and engineering services, has improved the functionality of VXinspect dimensional inspection software, including additional geometric dimensioning and tolerancing (GD&T) capabilities, cross-sections options, and more.
Part of VXelements, Creaform’s 3D software platform and application suite, VXinspect dimensional inspection software allows operators to set up a complete inspection sequence combining probing, 3D scanning, and photogrammetry. Its ergonomic and consistent software interface reduces the need for extensive training, lowers the risk of operator error, and increases productivity.
Enhancements in this new release include:
- Advanced GD&T module: True position and profile tolerance calculation for free-state and not fully constrained datum reference frames (DRF). Patten entity with composite tolerances features also available.
- Cross-section module: Creation methods for single and multiple cross-sections allowing 2D comparison.
- New alignment method
VXinspect is optimized for Creaform’s 3D measurement technologies.
Creaform’s latest microsite dedicated to quality control is www.creaform-metrology.com.
Creaform is a unit of AMETEK Ultra Precision Technologies, a division of AMETEK Inc., Berwyn, Pennsylvania.
Source: Creaform
