Machine operator interface

Machine operator interface

July 1, 2019

Wago Corp.

https://www.wago.com/us/
Automation Software

WAGO’s line of operator interface devices, Touch Panel 600 line, brings high-tech screens and high-quality visualizations to allow users to accompany their machines with advanced features. The engine has a Cortex A9 multicore processor providing fast operating speeds. On board security include a built-in firewall and VPN to help users address cyber attaches. All panels are equipped with the future-ready Linux operating system and support HTML5 technology.

The Touch Panel 600 line includes three versions to give users flexibility to use the right technology that fits their application and budget. These versions include:

  • Control Panel: Offers control and visualization to be performed simultaneously for an all in one automation solution
  • Visu Panel: Offers greater performance by splitting the responsibility of control and graphic visualization with the PLC controller
  • Web Panel: An industrial web browser optimized to operate with WAGO’s e!COCKPIT based PFC100 and PFC200 controllers

All of the Touch Panel 600s offer practical features such as an energy-saving standby function, integrated sensors for automatic brightness adjustment and an easy-to-mount design to make installation and operation simple.
